Hub M2
Supports up to 128 Zigbee child devices with multi-protocol (Zigbee 3.0, IR) gateway for maximum compatibility and future-proofing. Compatible with popular ecosystems such as Apple Home, Amazon Alexa, Google Home, IFTTT, etc.
Zigbee 3.0 Support
360° Infrared Control
Built-in Speaker
MicroUSB Power
Product Info
Description
The Aqara Hub M2 is a powerful smart home hub that connects and controls up to 128 Aqara devices via Zigbee 3.0, Wi-Fi, Bluetooth, and Infrared. It enables fast, stable communication and features a built-in infrared transmitter for controlling TVs, air conditioners, and more. Compatible with Apple HomeKit, Google Home, Alexa, and IFTTT, it supports seamless automation and voice control. The hub offers wired Ethernet or Wi-Fi connectivity and local automation, ensuring reliability even without internet. With its compact design and broad compatibility, the Aqara Hub M2 is an ideal choice for a smart, efficient, and future-proof home.
Key Features
- Zigbee 3.0 Support, up to 128 devices: Connect and manage all your Aqara devices with the latest, fastest, and most energy-efficient technology.
- 360° Infrared Control: Control your IR devices from anywhere in the room with voice commands** and local automations.
- Ethernet RJ-45 Port: Enjoy extra stability and faster response times with a wired Ethernet connection.
- Built-in Speaker: Use as an alarm or doorbell, customizable through automations.
- USB Power: Offers flexible installation options and optional battery backup with Micro-USB 5V 1A power support.
- All-Round Compatibility: Seamlessly integrate with your favorite voice assistant** or smart home ecosystem via the Aqara Home app.
- Supports all 4 Apple HomeKit native alarm modes.
Note:
* Up to 128 Aqara Zigbee child devices can be connected to the hub (repeater devices such as Smart Plug and Wall Switch (with Neutral) are required).
**Apple Siri, Amazon Alexa, Google Assistant, and more are supported.
Specifications
| Category | Hub |
| Colour | Black |
| Model | HM2-G01 |
| Wireless Protocols | Wi-Fi iEEE 802.11 b/g/n 2.4GHz, Zigbee 3.0 iEEE 802.15.4, BLE 5.0 |
| Dimensions | 100.5×30.75mm (φ3.95×1.21 in.) |
| Input Power | 5V 1A or 5V 2A |
| Ports | RJ-45 |
| Operating Temperature | 5°C~+50°C (23°F~122°F) |
| Operating Humidity | 0~95% RH, no condensation |
| Support System | Android 6.0 or iOS 12.0 and above |
| Wi-Fi Operation Frequency | 2412-2472 MHz |
| Wi-Fi Maximum Output Power | < 20 dBm |
| Bluetooth Operation Frequency | 2402-2480 MHz |
| Bluetooth Maximum Output Power | < 13 dBm |
| Input Power | 5V 1A or 5V 2A |
| Zigbee Operation Frequency | 2405-2480 MHz |
| Zigbee Maximum Output Power | < 13 dBm |
| What is in the Box | Hub M2 × 1, User Manual × 1, Micro USB to USB-A cable × 1 |
Product Support Documents
- Step by step installation instruction video:
Installation Video (00:07:09) - Product User Manual:
User Manual (PDF) - Product FAQs:
Frequently Asked Questions (PDF)
